PCB Card Guides are designed to guide, support, and accurately position printed circuit boards (PCBs) and plug-in modules inside 19-inch subracks, card cages, and modular electronic systems.
About this
product
The card guides provide a controlled insertion and removal path for PCBs while helping prevent lateral movement, PCB edge damage, and misalignment with backplane connectors.
Available in different lengths, groove widths, mounting configurations, materials, and colors, our PCB Card Guides can be supplied as standard components or customized according to customer drawings and application requirements.
Products description
For1.6-2.0mm thickness PCB boards
Codable, coding chamber for mounting
coding pegs
Performance description
IEC 60297-3-103
Railway Fire Standard EN 45545-2:2013+A1:2015(E)
High-Temperature Aging 90°C / 6 h
Aging Standard GB/T 7141-2008
Low-Temperature Test -55°C
Embrittlement Standard GB/T 5470-2008
RoHS 2011/65/EU
Material: PC+GF
